SPEC
body shape    AEWC specially designed comfort body
top    Solid Spruce top
back & sides    Flamed Maple back & Flamed Maple sides
neck    AEWCNyatoh neck
fretboard    Walnut fretboard
bridge    Walnut
inlay    Off-set white dot inlay
soundhole rosette    Abalone
tuning machine    Chrome Classical tuners
nut material    Plastic
number of frets    20
saddle material    Plastic
strings    Ibanez ICLS6NT
string gauge    .0280/.0322/.0403/.029/.035/.043
string space    11.6mm
factory tuning    1E,2B,3G,4D,5A,6E
pickup    Fishman® Sonicore
preamp    Ibanez AEQ-SP2 preamp w/Onboard tuner
output jack    Balanced XLR & 1/4″ outputs

NECK DIMENSIONS
Scale :    648mm
a : Width    46mm at NUT
b : Width    58mm at 14F
c : Thickness    21mm at 1F
d : Thickness    22mm at 7F
Radius :    Flat

BODY DIMENSIONS
a : Length    19 1/4″
