SPECS

• neck type
• GRXMaple neck
• top/back/bodyQuilted Maple Art Grain (Basswood) topPoplar body
• fretboardJatoba fretboardWhite dot inlay
• fretMedium frets
• number of frets22
• bridgeT106 bridge
• string space10.5mm
• neck pickupInfinity R (H) neck pickupPassive/Ceramic
• middle pickupInfinity RS (S) middle pickupPassive/Ceramic
• bridge pickupInfinity R (H) bridge pickupPassive/Ceramic
• factory tuning1E,2B,3G,4D,5A,6E
• string gauge.009/.011/.016/.024/.032/.042
• hardware colorChrome

NECK DIMENSIONS

• • Scale :648mm/25.5″
  • a : Width42mm at NUT
  • b : Width57mm at 22F
  • c : Thickness19.5mm at 1F
  • d : Thickness21.5mm at 12F
  • Radius :305mmR

SWITCHING SYSTEM

GRX70QAL’s Switching system diagram

CONTROLS

GRX70QAL’s control diagram

Features

Maple neck

Maple neck

The Maple neck provides stability and bright tonal character.

T106 tremolo bridge

T106 tremolo bridge

The T106 tremolo bridge with 6 independent saddles makes precise height and intonation adjustment of each string easy.

Mono-unit output jack

Mono-unit output jack

The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.

Infinity R H-H pickups

Infinity R H-H pickups

Ibanez Infinity pickups deliver an accurate and tight sound with excellent dynamics. Even under heavy settings, they do not lose tonal clarity.

Jatoba Fretboard

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
